The PAX A80 is a modern SmartPOS desktop terminal powered by Android 10. Built for fast, secure payments, it combines a bright 4" display, advanced connectivity and a compact desktop design ideal for a wide range of businesses.
Built for your business
- Food & Beverage
- Fashion & Retail
- Convenience
Powered by Android 10
A modern SmartPOS platform running Android 10 for a fast, flexible and app-ready experience.
PCI 6.x SRED
Meets the latest PCI 6.x SRED security standards to keep every transaction protected.
4" Display
A bright, responsive 4" touchscreen for easy operation and clear customer prompts.
0.3MP Front Camera
A front-facing camera adds scanning and additional capabilities at the point of sale.
Advanced Connectivity
Dual-band Wi-Fi, LAN and Bluetooth 5 keep the terminal reliably connected.
Specifications
| Operating System | PAXBiz Powered by Android 10 |
|---|---|
| Processor | 64 Bit Quad-core Cortex-A53 1.6GHz |
| Memory | 1GB DDR + 8GB eMMC | 1 microSD Card Slot, Supports up to 32GB |
| Card Readers | Chip & PIN | NFC Contactless | Magnetic Stripe |
| Cameras | 0.3MP Front-Facing |
| Displays | 4'' TFT WVGA 480 x 800 Pixels | Multi-Point Capacitive Touch Screen |
| Comms Configurations | Dual-Band Wi-Fi 2.4GHz/5GHz | LAN | Bluetooth 5 |
| Battery | *Optional: 720mAh | 7.4V |
| Printer | 50 lines/sec | Paper Roll Outer Diameter: 50mm |
| SIM / SAM | 3 SAM |
| Keys / Buttons | 15 Keys: 0 ~ 9 | Menu | Func | Cancel | Clear | Enter |
| Audio | 1 Speaker |
| Ports | 1 RS232 | 1 LAN Ethernet | 1 PIN pad | 1 micro-USB 2.0, OTG | 1 Host USB 2.0 |
| Adapter | Input: 100-240V AC, 50Hz/60Hz | Output: 9.0V DC, 1.0A |
| Physical | 181 x 84 x 81mm, 405g (excluding battery) |
| Environmental | -10°C ~ 50°C (14°F ~ 122°F) Operating Temperature | -20°C ~ 70°C (-4°F ~ 158°F) Storage Temperature | 5% ~ 96% Relative Humidity, Without Condensation |
| Optional Accessories | Cluster Cable | Privacy PIN Shield |
| Certifications | PCI PTS 6.x SRED | EMV L1 & L2 | EMV contactless L1 | Visa payWave | Mastercard contactless | American Expresspay | Discover D-PAS | Geobridge | JCB J/Speedy | Interac Flash L2 | Mastercard TQM | IC | CE | RoHs | UL | FCC |
*Optional terminal features require the creation of a new Part Number, and minimum order quantities apply.
